LOCATION MAP
STATE OF OHIO
DEPARTMENT OF TRANSPORTATION
D07 GR TYPE A REPLACEMENT
CENTERVILLE, CLAYTON, DAYTON, EASTERN HILLS, HUBER HEIGHTS, MIAMISBURG, MORAINE, OAKWOOD, PIQUA, RIVERSIDE, SPRINGFIELD, WEST CARRALTON
CLARK, MIAMI, MONTGOMERY
INDEX OF SHEETS:
| TITLE SHEET | 1 |
| LOCATION MAPS | 2-5 |
| GENERAL NOTES | 6-7 |
| MAINTENANCE OF TRAFFIC | 8 |
| GENERAL SUMMARY | 9 |
| ESTIMATED QUANTITIES | 10 |
| PLAN SHEETS | 11-38 |
STAGE 3
FEDERAL PROJECT NUMBER
E201 (149)
CONSTRUCTION PROJECT NUMBER
NONE
RAILROAD INVOLVEMENT
NONE
PROJECT DESCRIPTION
THE INTENT OF THIS PROJECT IS THE REMOVAL OF NON-CRASHWORTHY TYPE "A" END TERMINALS FROM NHS ROUTES IN VARIOUS LOCATIONS.
EARTH DISTURBED AREAS
PROJECT EARTH DISTURBED AREA: N/A ACRES
ESTIMATED CONTRACTOR EARTH DISTURBED AREA: N/A ACRES
NOTICE OF INTENT EARTH DISTURBED AREA: N/A ACRES
(ROUTINE MAINTENANCE PROJECT)
LIMITED ACCESS
THIS IMPROVEMENT IS ESPECIALLY DESIGNED FOR THROUGH TRAFFIC AND HAS BEEN DECLARED A LIMITED ACCESS HIGHWAY OR FREEWAY BY ACTION OF THE DIRECTOR IN ACCORDANCE WITH THE PROVISIONS OF SECTION 5511.02 OF THE OHIO REVISED CODE.
2019 SPECIFICATIONS
THE STANDARD SPECIFICATIONS OF THE STATE OF OHIO, DEPARTMENT OF TRANSPORTATION, INCLUDING SUPPLEMENTAL SPECIFICATIONS LISTED IN THE PLANS AND CHANGES LISTED IN THE PROPOSAL SHALL GOVERN THIS IMPROVEMENT.
DESIGN EXCEPTIONS
NONE
NONE
UNDERGROUND UTILITIES
PLAN PREPARED BY:
ODOT DISTRICT 7 - ENGINEERING
1001 ST. MARY'S AVE.
SIDNEY, OHIO
ODOT DISTRICT 7 - ENGINEERING
1001 ST. MARY'S AVE.
SIDNEY, OHIO
ENGINEER'S SEAL:
SIGNED: _______________________ DATE: ___________
| STANDARD CONSTRUCTION DRAWINGS | SUPPLEMENTAL SPECIFICATIONS | SPECIAL PROVISIONS |
| DM-4.3 1/15/16 | MT-95.31 7/19/19 | 800-2019 1/15/21 | |
| DM-4.4 1/15/16 | MT-95.45 1/17/20 | 832 10/19/18 | |
| MT-97.10 4/19/19 | |||
| BP-5.1 1/18/19 | MT-98.10 1/17/20 | ||
| MT-98.20 4/19/19 | |||
| MGS-1.1 1/19/18 | MT-98.22 1/17/20 | ||
| MGS-2.1 1/19/18 | MT-98.28 1/17/20 | ||
| MGS-3.1 1/19/18 | |||
| MGS-3.2 1/18/13 | TC-61.30 7/19/19 | ||
| MGS-4.1 1/20/17 | |||
| MGS-4.2 7/19/13 | |||
| MGS-4.3 1/18/13 | |||
| MGS-5.2 7/15/16 | |||
| MGS-5.3 7/15/16 | |||
| MT-95.30 7/19/19 |
I HEREBY APPROVE THESE PLANS AND DECLARE THAT THE MAKING OF THIS IMPROVEMENT WILL NOT REQUIRE THE CLOSING TO TRAFFIC OF THE HIGHWAY AND THAT PROVISIONS FOR THE MAINTENANCE AND SAFETY OF TRAFFIC WILL BE AS SET FORTH ON THE PLANS AND ESTIMATES.
APPROVED DATE DISTRICT DEPUTY DIRECTOR
APPROVED DATE DIRECTOR, DEPARTMENT OF TRANSPORTATION
DESIGN AGENCY
DISTRICT 7 ENGINEERING
DISTRICT 7 ENGINEERING
| DESIGNER | ANW |
|---|---|
| REVIEWER | XXX MM-DD-YY |
| PROJECT ID | 113767 |
| SHEET | P.1 |
| TOTAL | 38 |
