Zoning & Cadastral Boundary Map

Burlington Drive, Inlow Springs Road, and West Fork White River Vicinity

Cadastral plat map showing parcel dimensions, flood area boundary, and zoning districts including Farming, Residence Zone 1, and Residence Zone 2 along Burlington Drive and Inlow Springs Road.

Accessible view

Overview & Geographic Features

Major Roads: Burlington Dr (bottom parcel boundary, length callout 640.19 ft) and Inlow Springs Rd (top-right corner).
Waterways: W. Fork White River traversing horizontally through the upper-middle section.
Key Identifiers / Tract Numbers: (200), (476), (126), and (451).

Zoning Districts

Farming: Upper northern section (dimensions 426.01, 1319.55, 1447.64, 1427.39, 1468.1) and bottom area below Burlington Dr.
Residence zone 2: Highlighted in yellow along Inlow Springs Rd (top right) and along Burlington Dr (bottom central tracts, frontages: 550 ft, 425.57 ft, 114.86 ft, 280.73 ft).
Residence Zone 1: Area marked with circled identifier (200) east of the main tract boundary.
Flood Area: Shaded teal/cyan region encompassing the riparian corridor and interior parcel area extending to vertical boundary line 2682.17 ft.

Key Parcel Boundary Measurements

Each row below represents one legible dimension callout on the map; orientation and map position distinguish adjacent segments.

On narrow screens, scroll horizontally to view all table columns.

Boundary segments and dimensions transcribed from the map (feet)
Parcel / map location	Orientation or map relationship	Zoning / area qualifier	Dimension (ft)
Upper-left farming parcel	North boundary, west segment	Farming	672.75
Upper-left farming parcel	West boundary, north–south segment	Farming	1299.75
Upper central farming parcel	North boundary, west–east segment	Farming	426.01
Upper central farming parcel	North boundary, adjacent west segment	Farming	1049
Upper central parcel	North boundary at the flood-area edge	Farming / Flood Area boundary	299.64
Upper farming parcels	North–south boundary, west interior line	Farming	1319.55
Upper farming parcels	North–south boundary, central-west interior line	Farming	1447.64
Upper farming parcels	North–south boundary, central interior line	Farming	1427.39
Upper farming parcel	North–south boundary, east interior line	Farming	1468.1
Flood-area tract 200	Main vertical boundary	Flood Area / tract (200)	2682.17
Residence zone 2 parcel on Burlington Dr	Upper boundary/frontage-side segment	Residence zone 2	550
Residence zone 2 parcel on Burlington Dr	Burlington Dr frontage	Residence zone 2	640.19
Residence zone 2 parcel on Burlington Dr	Burlington Dr frontage, east adjoining segment	Residence zone 2	114.86
Residence zone 2 parcel south of the main tract	North boundary, west–east segment	Residence zone 2	425.57
Residence zone 2 parcel south of the main tract	Interior boundary, north–south segment	Residence zone 2	280.73
Residence zone 2 parcel south of the main tract	Interior boundary, north–south segment	Residence zone 2	244.65
Residence zone 2 parcel south of the main tract	Interior boundary, north–south segment	Residence zone 2	252.37
Residence Zone 1, tract (200)	Upper boundary, west–east segment	Residence Zone 1 / tract (200)	488
Residence Zone 1, tract (200)	Interior boundary, north–south segment	Residence Zone 1 / tract (200)	288.94
Residence Zone 1, tract (200)	Eastern boundary, north–south segment	Residence Zone 1 / tract (200)	364.81
Residence Zone 1, tract (200)	Eastern boundary, adjoining segment	Residence Zone 1 / tract (200)	370.07
Eastern tract boundary	Southeast diagonal boundary segment	Residence Zone 1 / tract (200)	669.38
