TAX MAP • BOROUGH OF SOMERVILLE

SOMERSET COUNTY, NEW JERSEY — SHEET 8

SHEET 8 SCALE: 1″ = 100′ REVISED: JAN. 2024
Cadastral Survey Map North Arrow: VAR. 10° 21′ W Adjoining Sheets: 3, 7, 9, 9.02, 11
Status: To Show Conditions as of January 2024 Open full-size map
Tax Map Sheet 8, Borough of Somerville, Somerset County, New Jersey showing Blocks 73, 74, 75, 75.01, 76, 76.01, 77, 78, 79, 80, 81, 82 and street grid

Title Block & Certification

Municipality Borough of Somerville
County / State Somerset County, NJ
Original Survey Date September, 2013
Licensed Land Surveyor Brendan J. Nally, GS31662
Municipal Offices 25 West End Ave, Somerville NJ 08876
State Certification: This sheet was formally certified on September 17, 2014. Assigned Serial Number #1046 and signed by Sue Davison, CTA Supervising Field Rep.
CAD/D Note: This map has been redrawn using Computer Aided Drafting / Design (CAD/D) based on the map prepared by Thomas F. Bliss, P.E. & L.S. Licence No. 7003, dated 10-4-63.

Revisions Schedule

Date Name Lic. No.
SEPT. 2013 BRENDAN J. NALLY 31662
JAN. 2014 BRENDAN J. NALLY 31662
JAN. 2015 BRENDAN J. NALLY 31662
JAN. 2017 BRENDAN J. NALLY 31662
JAN. 2018 BRENDAN J. NALLY 31662
JAN. 2019 BRENDAN J. NALLY 31662
JAN. 2024 BRENDAN J. NALLY 31662

Sheet Contents & Insets

Tax Blocks Shown:
Block 73 Block 74 Block 75 Block 75.01 Block 76 Block 76.01 Block 77 Block 78 Block 79 Block 80 Block 81 Block 82
Streets Included:

East Spring Street, Walnut St., Sycamore Street, Culver Street, North Gaston Avenue, East Cliff Street, Bartine Lane, Catherine Street, William Street, East Summit Street, North Bridge Street, Grove Street, Reimer St., Union Ave.

Insert “A” (Park Heights Villas):
Block 75.01, Lot 1.01 1.62 Ac. Total (C.E.)
Model A (Lots 1–7, 9–22) 570 Sq. Ft. (38′ × 15′)
Model B (Lot 8) 543 Sq. Ft. (38′ × 15′)
