Parcel Plat & Zoning Overview Map

GIS land survey showing lot boundaries, zoning classifications, roadway corridors, and key property dimensions.

Detailed GIS plat map showing parcel boundary lines, residential R3 zoning districts, street alignments, water features, and lot dimension callouts.

Figure 1: GIS Plat Survey showing lot divisions, road networks (396 E RD, 740 S RD, 354 E RD, 400 E RD), and zoning districts.

Identified Parcel IDs

Parcel Number Zoning / Type
1619202001000 R3
1619251001000 R3
1619283001000 R3
1620102009000 R3
1620153001000 R3
1620300001000 R3
1619400001000 F / Open Space
1619400005000 F / Open Space
1619400012000 F / Open Space

Roadways & Boundary Dimensions

Road / Feature Boundary Measurements
396 E RD 2178.7 ft
740 S RD 760.47 ft
354 E RD 2310.00 ft
400 E RD 516.58 ft
Segment 486.69 486.69 ft
Segment 333.24 333.24 ft
