Corporation Line Adjustment, Kettering/Oakwood, Fairmont Avenue Area
Responsive line drawing of the survey exhibit. It shows the 2nd Fairmont Plat lots 83 through 90, P.B. M, page 44 lots 59 through 64, the existing Oakwood and Kettering corporation lines, Fairmont Avenue, Dorothy Lane, and the area and tract notes.
CORPORATION LINE ADJUSTMENT
KETTERING/OAKWOOD
FAIRMONT AVENUE AREA
SECTION 36, TOWN 2, RANGE 6 M.Rs.
MONTGOMERY COUNTY, OHIO
DECEMBER 2021
REFERENCE MONTGOMERY
COUNTY ENGINEER'S OFFICE
RECORD OF LAND SURVEYS
VOLUME 21-0417
TOTAL AREA
TO OAKWOOD
0.113 AC.
2.904 ACRE TRACT
LOT # 2867
(TAX PARCEL ID #
Q71 01103 0017)
FAIRMONT AVENUE
EX. OAKWOOD CORP. LINE
PER R.I.D. DEED 2016-04598
EX. KETTERING CORP. LINE
2ND FAIRMONT PLAT
LOT 90 LOT 83
LOT 89 LOT 84
LOT 88 LOT 85
LOT 87 LOT 86
EX. OAKWOOD CORP. LINE
PER P.B. "R", PG. 96
EX. KETTERING CORP. LINE
PER P.B. "D", PG. 25
P.B. "M", PG. 44
LOT 59
LOT 60
LOT 61
LOT 62
LOT 63
LOT 64
159+00 160+00 161+00 162+00
SECTION 36 SECTION 35
DOROTHY LANE
* PART LOT 59 (0.0104 AC)
D.B. 2248-Pg. 574
PREPARED BY:
CITY OF KETTERING
CORPORATION LINE ADJUSTMENT
KETTERING/OAKWOOD
FAIRMONT AVENUE EXHIBIT
HORIZ. SCALE
IN FEET (1"=60')
3600 Shroyer Road
Kettering, OH 45429
Responsive vector reconstruction of the survey exhibit. The original scanned exhibit is available below for visual verification; the labeled notes are also provided as selectable text.
Open original scanned exhibit (zoomable)
Plat labels and survey notes
Reference: Montgomery County Engineer's Office, Record of Land Surveys, Volume 21-0417.
Area and tract: Total area to Oakwood: 0.113 Ac.; 2.904 Acre Tract, Lot # 2867; Tax Parcel ID # Q71 01103 0017.
2nd Fairmont Plat: Lots 83, 84, 85, 86, 87, 88, 89, 90.P.B. "M", Pg. 44: Lots 59, 60, 61, 62, 63, 64.Existing lines: Ex. Oakwood Corp. Line per P.B. "R", Pg. 96; Ex. Kettering Corp. Line per P.B. "D", Pg. 25.Roadways: Fairmont Avenue and Dorothy Lane.Stationing shown: 159+00, 160+00, 161+00, 162+00; Sections 35 and 36.Area note: * Part Lot 59 (0.0104 AC), D.B. 2248-Pg. 574.Preparation and scale: Prepared by City of Kettering; 3600 Shroyer Road, Kettering, OH 45429; horizontal scale in feet (1" = 60').
Reference Information
Montgomery County Engineer's Office: Record of Land Surveys, Volume 21-0417
Total Area to Oakwood: 0.113 Ac.
Tract Info: 2.904 Acre Tract, Lot # 2867 (Tax Parcel ID # Q71 01103 0017)
Plat Details
2nd Fairmont Plat: Lots 83, 84, 85, 86, 87, 88, 89, 90P.B. "M", Pg. 44: Lots 59, 60, 61, 62, 63, 64Roadways: Fairmont Avenue, Dorothy Lane
Preparation & Scale
Prepared By: City of Kettering
3600 Shroyer Road, Kettering, OH 45429
Horizontal Scale: 1" = 60'
×
