Attachment A-1
GAI Consultants
Bridge Replacement - Bridge 5
Delaware County, IN
← Scroll horizontally to view entire table →
|
FIELD SURVEY FEE COMPUTATIONS |
PRINCIPAL ENGINEER (PE) /
PRINCIPAL SURVEYOR (L.S.) |
PROJECT ENGINEER (PE) /
PROJECT SURVEYOR (PLS) |
SENIOR TECHNICIAN
|
TECHNICIAN
|
CLERICAL
|
ONE PERSON
SURVEY CREW |
TWO PERSON
SURVEY CREW |
TOTAL HOURS | TOTAL FEE |
|---|---|---|---|---|---|---|---|---|---|
| CLASSIFICATION | |||||||||
| TASK DESCRIPTION | |||||||||
| FIELD SURVEY | 0 | 3 | 8 | 16 | 3 | 8 | 18 | 56 | $7,806 |
| Prepare/mail Notice of Survey letters | 1 | $80 | |||||||
| Utility Notification | 2 | $160 | |||||||
| Setup Vertical Control (TBM & BM) | 2 | $420 | |||||||
| Deed Research for R/W Line and P/L | 4 | $340 | |||||||
| Verify Exisitng R/W and P/L | $- | ||||||||
| Set/witness Control Network | 2 | $420 | |||||||
| Level Circuit for Project | 2 | $420 | |||||||
| Topo Data Collection @ approx 50' interval | |||||||||
| Along County Road W 850 N. (500 LF) | 8 | $976 | |||||||
| Along Creek - Upstream and Downstream (500') | 10 | $2,100 | |||||||
| Structure Datasheet | 2 | 2 | $590 | ||||||
| Structure Pipe Network | $- | ||||||||
| Locate R/W markers-property corners | $- | ||||||||
| Edit / Import Data | 2 | $244 | |||||||
| Surface Creation | 2 | $244 | |||||||
| CADD Clean up | 2 | 6 | $754 | ||||||
| Re-establish Alignment from plans | 1 | 1 | $280 | ||||||
| Assemble Field Book /Notes | 1 | 1 | 4 | $620 | |||||
| Project Mangement, Coordination & QA | 1 | $158 | |||||||
| TOTAL HOURS | 0 | 3 | 8 | 16 | 3 | 8 | 18 | 56 | |
| HOURLY RATE (2026) | $239.00 | $158.00 | $122.00 | $85.00 | $80.00 | $122.00 | $210.00 | ||
| TOTAL LABOR COST | $0.00 | $474.00 | $976.00 | $1,360.00 | $240.00 | $976 | $3,780 | $7,806 | |
| DIRECT EXPENSES - Mob - Port to Port | 3 | Mobs @ | $ 100.00 | per Trip | = | $300.00 | |||
| DIRECT EXPENSES (LODGING) | Nights @ | $ 200.00 | per night | = | $- | ||||
| DIRECT EXPENSES (PER DIEM) | Days @ | $ 40.00 | per day | = | $- | ||||
| TOTAL FEE | $8,106 | ||||||||
