SCOPE OF SERVICES AND FEE PROPOSAL

Date of Proposal:

August 3, 2026

Project Description:

Delaware County Bridge No. 5 Full Replacement, Delaware County Highway Department.

APEX CONSULTING & SURVEYING, INC. (APEX) shall provide field surveying services for the above-mentioned project bridge number. APEX shall furnish all labor, materials, and equipment to perform the surveying services described below for the attached fee.

Field Surveying Services

BASIC SERVICES

APEX shall survey the project location and provide one set of original field notes, all field survey data collected via electronic media, and one set of master drawings. APEX shall obtain section corner, right-of-way, easement, and state plane coordinate information as necessary to satisfactorily complete the basic field survey services described herein within the project limits.

Electronic files including the following shall be prepared and submitted by APEX as directed by client:

1. Finished plan view of topographic survey in AutoCAD .dwg format.

2. 1-foot contours in AutoCAD .dwg format

3. TIN from Civil 3D in .xml format

4. Electronic points file in .txt or .xml coordinate format.

5. Survey Book in .pdf format.

The signature, seal, and registration number of the land surveyor, registered in the State of Indiana, who was in responsible charge of the survey, shall be affixed to the survey book submitted. In addition, APEX shall complete the field survey as summarized below and as directed by the Client. The project area and survey limits to be field surveyed and described as follows:
