MOT-CR-609 SHROYER ROAD IMPROVEMENTS

Pavement Markings — STA. 55+33 to STA. 66+53 (Sheet 49 of 54)

Civil Engineering Plan Sheet for MOT-CR-609 Shroyer Road Improvements showing pavement markings from Station 55+33 to Station 66+53, including lane layouts, callouts, right-of-way lines, intersection details, and City of Kettering engineering title block.
Sheet Summary: Detailed engineering plan view showing proposed pavement markings, lane widths, turn lane geometries, bike lane configurations, RTA bus stop locations, and stationing callouts along Shroyer Road between STA. 55+33 and STA. 66+53. Includes City of Kettering standards, scale bar, north arrow, and project reference number 02-124i.
