Prodigy Building Solutions, LLC
9652 Inter Ocean Drive
West Chester, OH 45246
Oakwood High School – Backstop Netting
Backstop, In-line Permanent
Model #BSP
Overall Height: 30’
- Backstop: 3’ high block wall with pads, 27’ high netting
-
First base foul line: 6’ high black metal fence with 2 gates, 24’ high netting
- Protective netting will extend 150’ from backstop toward right field
-
Third base foul line: 6’ high black metal fence with 2 gates, 24’ high netting
- Protective netting will extend 35’ from the backstop toward left field
The extended first base line netting is intended to enhance safety by protecting the nearby homes and pedestrians from foul balls. This is not necessary on the third base line due to the natural barrier created by trees and additional space created by the road.
Net Material: #36 Black twisted knotted nylon – 1-3/4” square
Net Mounting: Permanent
Pole Quantity: 7
Pole Mounting: Direct-bury
Pole Material: Steel
Pole Diameter: 8”
Pole Finish: Black, powder-coated
Life expectancy of netting: 15+ years
Oakwood High School – Backstop Wall Pads
Modular Backstop Wall
Model #MW-3
Overall Height: 3’
System Includes:
Galvanized steel fence posts
Powder-coated mounting brackets for direct connection to backstop support poles
Integrated attachments for backstop netting (netting sold separately)
Standard Pad size 2’-11” H x 4’ W (to be hung 1” above finish grade)
Connection: to modular wall
Construction 2” Thick foam with 18-oz UV-Treated vinyl cover
Each pad includes mounting brackets: Full length support batten and Velcro to secure bottom of pad wall
Color: Navy
