Shroyer Road Improvement Concept Plan

STA. 11+00 TO STA. 36+00
CITY OF OAKWOOD SHEET 01 / 03
Calculated By SAK
Checked By SAK
Horizontal Scale 1" = 50 FEET (0, 25, 50, 100 FT)
Project Limits STA. 11+00 TO STA. 36+00
Open full-size plan Opens the high-resolution drawing for zooming and panning.
Shroyer Road Improvement Concept Plan Engineering Drawing Sheet showing STA. 11+00 to STA. 36+00 with lane configurations, bicycle lanes, turn lanes, and signage.

Segment 1: STA. 11+00 to STA. 23+50

  • Matchline Limit STA. 11+00
  • Intersecting Street East Dorothy Lane
  • Intersecting Street Brydon Rd
  • Intersecting Street East Dr
  • Intersecting Street Claranna Ave
  • Intersecting Street Broad Blvd
  • Matchline Limit STA. 23+50

Segment 2: STA. 23+50 to STA. 36+00

  • Matchline Limit STA. 23+50
  • Intersecting Street Wonderly Ave
  • Intersecting Street Orchard Dr
  • Intersecting Street Triangle Ave
  • Intersecting Street Peach Orchard Rd
  • Matchline Limit STA. 36+00

Signage & Markings Legend

  • Keep Right Sign R4-7b
  • Right Lane Must Turn Right R3-7R
  • Lane Assignment / Control R3-5R / R3-5a (300 FT)
  • Distance Supplemental Plate W16-2aP
  • Bike Lane / Bike Lane Ends R3-17 / R13-17bP
  • Lane Reduction Transition W4-2R
  • Transit Facility Existing Bus Stop
